Asus Rampage V Edition 10

529
Sin iva437,19
¾
105,80€
52,90€
20 Opiniones Review
Estado
Producto en almacén, salida inmediata.
Marca
Asus - P/N: 90MB0Q00-M0EAY0 | Cod. Artículo: 100790
Envío
Desde 5.25 €.
Cantidad:

Disp:Disponibilidad:Disponibilidad:
Plazo de entrega estimado para envíos a península
Stocks: Tienda Murcia / Tienda Madrid 1
Ocasión:
A partir de 534.65€ en nuestro rastrillo. Ahorra -5.65€.
A partir de 602.8€ reacondicionado. Ahorra -73.80€.
Financiación
12, 20 y 30 meses sin intereses

Asus Rampage V Edition 10 opiniones

Ver más opiniones 20

R

raimont
18/05/2017

Hay un tema con esta placa que no se ha mencionado y puede ser de ayuda para las personas que se topen con el mismo problema que el mío. Yo instalé esta placa en un chasis modular Thermaltake Level 10 GT que es bastante grande de tamaño y compatible con formatos de placa ATX y EATX como es el caso de esta placa. Esta placa viene reforzada por detrás, en algunas zonas, con una chapas que protege los componentes electrónicos y aquí es donde viene la "historia", es decir es más gruesa por un lado que por otro; de tal modo que al colocarla, si la placa pilla parte de los orificios rematados con gomas que llevan las torres para pasar los cables, al atornillarla la placa se comba ligeramente porque dicha chapa trasera de refuerzo pega en las gomas. Resumiendo, si os coincide algún caso como este, o hay que quitar las gomas de los agujeros que protegen los cables de posibles cortes o hay que elegir bien el chasis para que la placa no ocupe parte de dichos agujeros. Yo personalmente quité las gomas y puse unas finitas debajo de la placa más que nada por precaución, aunque no pasa nada si la chapa trasera de refuerzo pega en el chasis ya que va aislada de la placa. Yo me di cuenta de ese defecto porque conectando los cables de power, led y demás vi los pines como torcidos y era porque se combaba algo todo el lado derecho de la placa. Por lo demás coincido con las demás opiniones, una placa extraordinaria.

Ventajas: Placa de muy buena calidad, muy fría y muy vistosa si te gustan los efectos de luces.

Desventajas: Pocos puertos usb 2.

¿Recomendaría su compra?  Sí

<2 años
de garantía
?30 días
de devolución
=100%
pago seguro
  • Características
  • Opiniones 20
  • Videos / Reviews 0
  • Preguntas 10

Te presentamos la Rampage V Ediotion 10 de Asus, una placa base copn socket Intel 2011-3 y chipset X99.

Especificaciones:

CPUIntel® Core™ i7 X-Series Processors on LGA 2011-v3 Socket
Supports 14nm CPU
Supports Intel® Turbo Boost Max Technology 3.0*
* The support of these features depends on the CPU types.
ChipsetIntel® X99 Chipset
Memory8 x DIMM, max. 128GB, DDR4
3333(O.C.)*/3300(O.C.)*/3200(O.C.)*/3000(O.C.)*/2800(O.C.)*/2666(O.C.)*/2400(O.C.)*/2133 MHz, non-ECC, un-buffered memory
Quad channel memory architecture
Supports Intel® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please refer to Memory QVL (Qualified Vendors List) for details.
Expansion Slots4 x PCIe 3.0 x16 slots (supports x16, x16/x16, x16/x8/x8, x16/x8/x8/x8 or x8/x8/x8/x8 mode with 40-LANE CPU; x16, x16/x8 or x8/x8/x8 mode with 28-LANE CPU)* [CPU]
1 x PCIe 2.0 x4 slot** [PCH]
1 x PCIe 2.0 x1 slot [PCH]
* The PCIE_X8_4 slot shares bandwidth with M.2 and U.2.
40-LANE CPU:
In 4-Way configuration, if the PCIEX_16/X8_1 is used in x16 mode, both U.2 and M.2 ports will be disabled.
28-LANE CPU:
In 2-Way and 3-Way configuration, U.2 port will be disabled.
** The PCIE_X4_1 slot shares bandwidth with front USB3_34 ports and back USB3.1_EC1_EA2 ports
If a X2 device is connected to the PCIEx4_1 slot, the front USB3_34 ports will be disabled.
If a X4 or higher device is connected to the PCIEx4_1 slot, both front USB3_34 and back USB3.1_EC1_EA2 ports will be disabled.
Multi-GPU SupportSupports NVIDIA® 4-Way/3-Way/Quad-GPU SLI™ Technology*
Supports AMD® 4-Way/3-Way/Quad-GPU CrossFireX™ Technology*
* 28-LANE CPUs can only support up to 3-Way SLI™/ 3-Way CrossFireX™
StorageNew Intel® Core™ i7 Processors
- 1 x M.2 PCIe 3.0 x4 Socket 3 with M Key, type 2260/2280/22110 (supports PCIe storage device only)*
- 1 x U.2 port (support PCIe 3.0 x4 NVM Express storage)*
* These ports share bandwidth with PCIEX8_4 slot
Intel® X99 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology 14 support
- 10 x SATA 6Gb/s ports
- Supports Intel® Smart Response Technology**
** These functions will work depending on the CPU installed.
LANGigabit Intel® LAN connection - 802.3az Energy Efficient Ethernet (EEE) appliance
Intel® I218-V Gigabit LAN- Dual interconnect between the integrated Media Access Controller (MAC) and physical layer (PHY)
Intel® I211-AT Gigabit LAN controller
Anti-surge LANGuard
ROG GameFirst Technology
Wireless Data NetworkWi-Fi 802.11 a/b/g/n/ac support 3x3 dual frequency band 2.4/5 GHz
Up to 1300Mbps transfer speed
Bluetooth v4.0
AudioSupremeFX 8-Channel High Definition Audio CODEC:
- SupremeFX Shielding Technology
- Dual Op-Amps
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
-Optical S/PDIF out port at back panel
Audio Features:
- Sonic Radar II
- Sonic Studio II
- DTS connect
USBIntel® X99 Chipset - supports ASUS USB 3.1 Boost
- 4 x USB 3.0 ports (4 ports at mid-board)*
- 6 x USB 2.0 ports (2 ports at back panel [black], 4 ports at mid-board)**
ASMedia® USB 3.1 Controller - support ASUS USB 3.1 Boost
- 4 x USB 3.1 ports (2 x Type-A [red] and 2 x Type-C ports at back panel)*
ASMedia® USB 3.0 - supports ASUS USB 3.1 Boost:
- 4 x USB 3.0 ports (at back paned [blue])
** Front USB3_34 ports and back USB3.1_EC1_EA2 ports share bandwidth with PCIEX4_1 slot.
If a X2 device is connected to the PCIEx4_1 slot, the front USB3_34 ports will be disabled.
If a X4 or higher device is connected to the PCIEx4_1 slot, both front USB3_34 and back USB3.1_EC1_EA2 ports will be disabled.** Front USB3_34 ports and back USB3.1_EC1_EA2 ports share bandwidth with PCIEX4_1 slot.
If a X2 device is connected to the PCIEx4_1 slot, the front USB3_34 ports will be disabled.
If a X4 or higher device is connected to the PCIEx4_1 slot, both front USB3_34 and back USB3.1_EC1_EA2 ports will be disabled.** Front USB3_34 ports and back USB3.1_EC1_EA2 ports share bandwidth with PCIEX4_1 slot.
If a X2 device is connected to the PCIEx4_1 slot, the front USB3_34 ports will be disabled.
If a X4 or higher device is connected to the PCIEx4_1 slot, both front USB3_34 and back USB3.1_EC1_EA2 ports will be disabled.** Front USB3_34 ports and back USB3.1_EC1_EA2 ports share bandwidth with PCIEX4_1 slot.
If a X2 device is connected to the PCIEx4_1 slot, the front USB3_34 ports will be disabled.
If a X4 or higher device is connected to the PCIEx4_1 slot, both front USB3_34 and back USB3.1_EC1_EA2 ports will be disabled.** Front USB3_34 ports and back USB3.1_EC1_EA2 ports share bandwidth with PCIEX4_1 slot.
If a X2 device is connected to the PCIEx4_1 slot, the front USB3_34 ports will be disabled.
If a X4 or higher device is connected to the PCIEx4_1 slot, both front USB3_34 and back USB3.1_EC1_EA2 ports will be disabled.
** 2 x USB 2.0 ports at mid-board share with ROG extension (ROG_EXT) port
SupremeFX Hi-Fi Hardware:
- 1 x ESS ES9018K2M SABRE DAC
- 2 x LM4562 Op amps
- 1 x TPA6120A2 Headphone amp
- 1 x Cirrus Logic CS5361
- 5 x RC4580 Op amps
Headphone Output Performance:
Supported formats: Up to 32-bit/384kHz and DSD 64/128*
Output (32Ohms): 4.8VRMS (720mW RMS per channel)
Output (600Ohms): 6.8VRMS (77mW RMS per channel)
THD+N @ 1K (-3dB): -104dB (<0.0007%)
Signal to Noise Ratio (A-weighted): -121.1dB
Crosstalk: -98dB
Rear I/O Ports:
- POWER : 1 x 6-pin PCIe power connector
- SIGNAL : 1 x USB 2.0 header
Front I/O Ports:
- 1 x Volume control knob
- 1 x 6.3mm headphone jack**
- 1 x 3.5mm headphone jack**
- 1 x 3.5mm mic/line in jack
Dimensions:
5.25" ODD drive bay Form Factor (14.5 x 4.2x 14cm [W x H x D])***
*Sample rates greater than 32-bit/96kHz and DSD are only supported when high speed mode is enabled.
**Only one of these jacks will be active at a given time
***The face of this device is designed to be flush with a standard drive bay with the knob extending 1cm
ROG Exclusive FeaturesExtreme Engine Digi+
- MicroFine Alloy Choke
- IR3555 PoweIRstage®
- 10K Black Metallic Capacitors
OC Zone
- ReTry button
- Safe Boot button
- LN2 Mode header
- Slow Mode switch
- Start button
- Reset button
- ProbeIt
- PCIe x16 lane switches
- DRAM channel switches
ROG RAMCache
ROG RAMDisk
AURA
KeyBot II
- One-click overclocking
- X.M.P.
- DirectKey
- CLr CMOS
- Power On
UEFI BIOS features :
- Extreme Tweaker
- Tweakers´ Paradise
- ROG SSD Secure Erase
- GPU.DIMM Post
- O.C. Profile
- Graphics Card Information Preview
Special FeaturesASUS Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ Power Control, Fan Xpert 3, and Turbo App
ASUS Wi-Fi GO! Module
- Wi-Fi 3x3 802.11 a/b/g/n/ac and Bluetooth v4.0
Media Streamer
- Pipe music or movies from your PC to a smart TV, your entertainment goes wherever you go!
- Media Streamer app for portable smartphone/tablet, supporting iOS 7 & Android 4.0 systems
HyStream
- Stream Android/iOS/Windows devices´ screen on your PC screen.*
* Contact your device vendor for supporting information.
ASUS Exclusive Features
- AI Suite 3
- USB 3.1 Boost
- AI Charger+
- Push Notice
ASUS EZ DIY
- USB BIOS Flashback
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS C.P.R.(CPU Parameter Recall)
- MemOK!
ASUS Q-Design
- ASUS Q-Code
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
Back I/O Ports1 x Clear CMOS button
1 x BIOS Flashback button
4 x USB 3.0 ports [blue]
4 x USB 3.1 ports (2 x Type-C [black] and 2 x Type-A [red])
2 x anti-surge LAN (RJ45) ports
1 x ASUS Wi-Fi GO! module (Wi-Fi 3x3 802.11 a/b/g/n/ac and Bluetooth v4.0)
1 x PS/2 keyboard/mouse combo port
2 x USB 2.0 ports [black]
1 x Optical S/PDIF out
5 x audio jacks
Internal I/O Ports2 x USB 3.0 connector support additional 4 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports [one connector via ROG_EXT header]
10 x SATA 6Gb/s connectors
1 x U.2 port
1 x M.2 PCIe 3.0 x4 Socket 3 with M Key, type 2260/2280/22110 (supports PCIe storage device only)*
1 x ROG extension (ROG_EXT) header
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
1 x 4-Pin H_AMP fan connector
3 x 4-Pin Chassis fan connectors
1 x 4-pin Water pump connector
1 x 5-pin EXT_FAN (Extension Fan) connector
1 x Thermal sensor connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x 4-pin EATX 12V power connector
1 x EZ Plug connector
9 x ProbeIt Measurement Points
1 x Power-on button
1 x Reset button
1 x Safe Boot button
1 x ReTry button
1 x LN2 mode jumper
1 x Slow mode switch
1 x DRAM channel switch
1 x PCIe x16 lane switch
1 x MemOK! button
1 x SLI/CFX switch
1 x BIOS Switch button
1 x System panel connector
1 x Aura RGB Strip Header
1 x TPM connector
1 x Front panel audio connector (AAFP)
1 x Thunderbolt header
Accessories1 x User guide
1 x USB drive with utilities and drivers
1 x ASUS 3T3R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
5 x 2-in-1 SATA 6Gb/s cables
1 x 4-Way SLI™ bridge
1 x 3-Way SLI™ bridge
1 x SLI™ bridge
1 x FAN_EXT card
1 x 3-in-1 thermistor cable
1 x Q-Connector Kit
2 x ROG coasters
1 x ROG fan label
1 x ROG cable label set
1 x M.2 screws kit
1 x Bracket for FAN_EXT card
1 x Wafer cable
1 x Cable for SupremeFX Hi-Fi
1 x CPU GUARD FOR LGA 2011-R3 HW(Haswell-E)
1 x CPU GUARD FOR LGA 2011-R3 BW(Broadwell)
1 x I/O frame
1 x AURA cable
BIOS128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS,
ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log,
F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.
ManageabilityWfM 2.0, WOL by PME, PXE
SoftwareDrivers
ROG GameFirst technology
ROG RAMDisk
ROG RAMCache
ROG CPU-Z
ROG Mem TweakIt
Kaspersky® Anti-Virus
ASUS WebStorage
ASUS Utilities
Operating System SupportWindows® 10*
Windows® 8.1*
Windows® 7
*64-bit supported only
Form FactorExtended ATX Form Factor, 12”x 10.7” (30.5cm x 27.2cm)
